FZ6-200-2 k series magnetic powder brake

FZ6-200-2 k series magnetic powder brake

 Product Information

Magnetic powder brake's brief introduction:

Magnetic powder brake is a kind of superior performance of the automatic control components, is the merger by the drive unit and the driven unit. It with magnetic powder as working medium, the exciting current to control means to achieve the purpose of control the brake or transfer torque. The output torque and excitation current show good linear relation, and has the advantages of fast response speed, simple structure, and is suitable for wire, cable, printing, packaging, textile, rubber, leather, metal foil tape processing, paper and paper products processing and related take-up device automatic tension control system.

Working principle of the magnetic powder brake

Magnetic powder brake is mainly brake, brake parts and controlling device. Some brake with the brake clearance of automatic adjustment device, in order to
